Photonis ECHO Gen 2+ Image Intensifier Tube

Rated 0 out of 5
(be the first to review)


SKU: TUBE-ECHO- Category: Tags: , Brand:


The Photonis ECHO Gen 2+ Image Intensifier Tube is the perfect tube for your next budget-minded Night Vision device build. With a high Figure of Merit (FOM) and fast Auto-Gating, ECHO commercial grade tubes serve many night vision applications for users that require the extra range and details at night without breaking the bank.

Tube Specs:
Tube: Photonis ECHO High Performance Gen 2
Color: filmless P43 green or P45 white
Gate: Auto-Gated
FOM: 1800+
SNR: Min. 26.5
Resolution: Min. 62  lp/mm
High Light Resolution (200 lux): 55 lp/mm
Opertaional Time: 5,000 hours
Halo: Max 0.95
EBI: Max. 0.5


The Echo Image Intensifiers are the high performance commercial image intensifiers by Photonis. Echo tubes are available in two high performance grades in both green or white phosphor offering the best option for any user.

Options available

ONYX – black & white vision



ONYX is the optional black and white night vision of Photonis.
Studies show that night-time scenes appear remarkably more natural in B&W versus the usual green. Photonis offers B&W night vision for those who want to have a natural vision at night. B&W provides clearer information about the contrast, shapes and shadows.

16 mm

16mm16mm tubes have been designed to meet the SWaP requirements of the modern armies:
reduced Size, Weight and minimum Power consumption, with state-of-the-art performance.
The weight of the 16mm Image Intensifier Tube has been reduced by 30 grams compared to standard ANVIS 18mm tube while its volume size has been reduced by 40%.

size comparison

*ECHO tubes will not have the same performance as 4G units or Gen 3 image intensifiers intended for military and LE applications, and while the ECHO does display some Out Off Band (OOB) sensitivity to high powered systems, they do not have sufficient sensitivity for operational use with lower powered OOB devices such as individual weapon aiming lasers and marking lights

**Per Photonis: The P43 Green Phosphor ECHO tubes have higher overall specs than the P45 White Phosphor

***ECHO tubes may have a maximum of 2 spots in Zone 2, or 3




Additional information

Weight .5 lbs
Dimensions 1 × 1 × 1 in

P43 Green Phosphor 11769, P45 White Phosphor 11769, P43 Green Phosphor 10160, P45 White Phosphor 10160
